Specs
| Dimensions | |
|---|---|
| Height | 61" (tall) |
| Length | 88.5" (long) |
| Weight | 231 lb |
| Width | 40.1" (wide) |
| Shipping Dimensions | 77.5"L X49"W X41"H |
| Dumping | |
|---|---|
| Dump Angle | 60° |
| Dumping Capacity | 32 Cuft, 240 Gallons |
| Engine | |
|---|---|
| Air Filter | Dual Element |
| Cooling Methods | Air |
| Displacement | 223 CC |
| Engine Type | OHV R225 |
| Ft Lbs Torque | 9.59 |
| Horsepower | 6.6 |
| Make | DR |
| Number Of Cylinders | 1 (w/ Cast-Iron Sleeve) |
| Oil Type | SAE 30W HD |
| RPM Speeds | 3800 |
| Starting Type | Electric |
| Fuel_System | |
|---|---|
| Fuel Capacity | 3.6 Quart (approx run time 1 hr depending on conditions) |
| Warranty | |
|---|---|
| Engine Warranty | 2 Year Residential Use, 1 Year Commercial Use |
| Machine Warranty | 2 Year Residential Use, 1 Year Commercial Use |
| Wheels_Tires | |
|---|---|
| Dimensions | 14" Diameter x 4.5" Wide |
| Number of Tires | 2 (1 Per Side)/Optional Dual Kit |
| Tire Size | Pneumatic 5.30/4.50-8 4 Ply - Tubed Tire |
| Towing | |
|---|---|
| Hitch Type | Single Point |
