Specs
| Dimensions | |
|---|---|
| Height | 61" (tall) |
| Length | 88.5" (long) |
| Weight | 313 lb |
| Width | 49.5" (wide) |
| Shipping Dimensions | 77.5"L X49"W X41"H |
| Warranty | |
|---|---|
| Engine Warranty | 2 Year Residential Use, 1 Year Commercial Use |
| Machine Warranty | 2 Year Residential Use, 1 Year Commercial Use |
| Wheels_Tires | |
|---|---|
| Dimensions | 14" Diameter x 4.5" Wide |
| Number of Tires | 4 (2 Per Side) |
| Tire Size | Pneumatic 5.30/4.50-8 4 Ply - Tubed Tire |
| Tread | Sawtooth |
| Engine | |
|---|---|
| Air Filter | Dual Element |
| Cooling Methods | Air |
| Displacement | 389 CC |
| Engine Type | OHV R390 |
| Ft Lbs Torque | 16.90 |
| Horsepower | 11.7 |
| Lubrication | Splash |
| Make | DR |
| Number Of Cylinders | 1 (w/ Cast-Iron Sleeve) |
| Oil Capacity | 37.2 oz |
| Oil Type | SAE 30W HD |
| Starting Type | Electric |
| Fuel_System | |
|---|---|
| Fuel Capacity | 6.9 Quart (approx run time 2-2.5 hr depending on conditions) |
| Towing | |
|---|---|
| Hitch Type | Single Hitch |
| Dumping | |
|---|---|
| Dump Angle | 60° |
| Dumping Capacity | 44 Cuft, 330 Gallons |
