Specs
| Dimensions | |
|---|---|
| Height | 35.4 in |
| Length | 83.6 in |
| Wedge Height | 7.94 in |
| Wedge Width | 1-3" |
| Weight | 549 lbs |
| Width | 40.6 in |
| Engine | |
|---|---|
| Horsepower | 9.2 HP |
| Make | DR |
| Number Of Cylinders | 1 |
| Fuel_System | |
|---|---|
| Fuel Capacity | 1.6 gals |
| Fuel Type | Gas |
| General | |
|---|---|
| Assembly | Some assembly required |
| Hydraulics | |
|---|---|
| Cylinder Size | 5" bore, 23.65" stroke |
| Hydraulic Component Rating | 3500 psi |
| Pump | 2 Stage, 13.0 gpm |
| Reservoir | 5 gal |
| Wheels_Tires | |
|---|---|
| Number of Tires | 2 |
| Tire Size | 16" |
| Warranty | |
|---|---|
| Engine Warranty | 2 years residential, 1 year commercial |
| Machine Warranty | 2 years residential, 90 days commercial |
| Towing | |
|---|---|
| Hitch Type | 2" Ball |
| Max Highway Speed | 45 mph |
| Towable | Yes |
| Splitting | |
|---|---|
| Average Cycle Time | 16 secs |
| Max Log Diameter | 30 in |
| Max Log Length | 25 in |
| Splitting Force | 34 tons |
