Kohler Diesel KSD 1403TC
Kohler Diesel KSD 1403TC
Kohler Diesel KSD 1403TC
Kohler Diesel KSD 1403TC

Kohler Diesel KSD 1403TC

Contact us for price

Stock status: Call Store for Availability

The KSD Series is the result of our global approach to the market and the customers. It’s simple, versatile and advanced. It’s the KSD Series, the latest platform of engines from Kohler.

  • Compliant with all emissions standards worldwide
  • Easy to integrate
  • Solutions compatible with all kind of machines
  • Electronic fuel injection
  • Durable components

Specs

Engine Type

4 stroke diesel with cylinder in line, cast iron crankcase, cast iron cylinder head

Model KSD1403TC
Power[1] kw (hp) 18.9(25.7)@3000rpm
Displacement cm3 (in3) 1391 (84.88)
Bore mm (in) 81 (3.2)
Stroke mm (in) 90 (3.5)
Maximum Torque[1] Nm (lb-ft) 105 (77.4)
Dry Weight kg (lbs) 127 (280)
Dimensions LxWxH mm (in) 599 x 482 x 447
(23.6 x 19 x 17.6)
Emissions Compliance
  • China Phase IV
  • EU Stage V
  • US Tier 4 Final
Engine Type Consumer

1 Performances measured according to ISO 14396 without final intake and exhaust line. Actual engine performances may be affected by accessories (intake and exhaust line, charging, cooling fan, etc.), application, ambient operating conditions (temperature, humidity, and altitude) and other factors.
